The CFDISK.1E (Floppy) allows CompactFlash modules to be used in any system that includes a standard IDE 40 pin connector.
Once the platform starts with the adapter and the CF card plugged in, the compactflash module appears to the system to be a standard disk drive.
Unlike other flash storage systems such DiskOn-Chip modules this solution does not require drivers or additional software to run the unit.
The CF card can be the primary boot device containing the OS and application.

This adapter comes with a standard IDE cable that gets plugged into the IDE controller and can be jumpered as either master or slave.
Comes with a Floppy Disk power connector.
Jumper configuration for master or slave.

Product Links:
Schematics

Features :

• Dimension: 2x4 inches
• Support CompactFlashTM cards (Type I & II) or a IBM MicrodriveTM
• Due to limitations in the CompactFlash specification, this adapter does not support hot insertion of cards.
• Floppy disk power connector.
• Board is fully assembled (not a kit).
• Transparent to the operating system and does not require any drivers
