Aerial.net :: Mimosa N5-X20, dish Twist-on antenna, 20dBi, 250mm

Mimosa » 100-00088

Mimosa N5-X20, dish Twist-on antenna, 20dBi, 250mm - 2-pack
[2584][100-00088]

Price: 66,33€

Order or Qty		Price
> 500€	5+	65,66€
> 1000€	10+	65,00€
> 2000€	20+	64,34€
> 5000€	40+	63,67€
> 10000€	100+	63,01€

Prices exclude VAT

In Stock: 2

Available quantity within
3-5 working days: 99

Order Qty:

UPC:	708747437423
EAN:	10000088

N5-X20 is parabolic directional antenna with gain 20dBi and beamwidth angle 12° for use with C5x units. C5x is connected with antenna by Twist-on connector which eliminates loss on VF cables and connectors.

Antenna is Dual-Slant, polarizations are turn over by 45°. The are 2pcs in package!

Product Links:
Product Page	Datasheet

Technical parameters

Specifications:
Connectors and Interfaces
RF connectors:	Twist-on port (Mimosa)
Physical characteristics
Wind load [km/h]:	200
Purpose:	Outdoor
Weight [kg]:	0,8
Depth [mm]:	83
Width [mm]:	270
Height [mm]:	270
Wireless features
MIMO, SISO:	2 x 2 (slant - 45° turned)
Polarization:	VH (slant)
Wireless frequency:	5 GHz
Azimuth beam width (-6dB) [°]:	12, 12
Antenna kind:	Directional
Antenna gain [dBi]:	20

Package Contents:
2 x N5-X20

Additional Images:

Return for:
Refund:	Store Credit:	Repair:
20 day(s)	40 day(s)	24 month(s)
