Ubiquiti PrismAP-5-90 (Horn-5-90), Symmetrical sector 5GHz antenna, 13dBi, 90°
[2050][Horn-5-90]
Price: 73,01€
 Order or Qty  Price
 > 500€  5+   72,28€
 > 1000€  10+   71,55€
 > 2000€  20+   70,82€
 > 5000€  40+   70,09€
 > 10000€  100+   69,36€
Prices exclude VAT

Ubiquiti PrismAP-5-90 (Horn-5-90), Symmetrical sector 5GHz antenna, 13dBi, 90°

Ships in:
3-5 working days
Quantity: 26
Order Qty:
UPC:817882020084

PrismAP-5-90

airMAX ac Beamwidth Sector Isolation Antenna Horns for PrismStation and IsoStation Designed for Increased Co-Location Performance Dual-Linear Polarization.

Ubiquiti Networks launches a new generation of airMAX ac beamwidth isolation antennas, the PrismAP.

With flexible sectorization for optional antenna beamwidths, the PrismAP antennas are interchangeable and improve beamshaping for specific deployment and environment needs.

The PrismStation 5AC and IsoStations use horn antenna sectors designed for increased colocation performance without sacrificing gain.

Unique beam performance and great co-location characteristics allow for a higher density of sectors than traditional sector technology.

Specifications:
Dimensions: 152.1 x 186.8 x 113.2 mm
Weight: 0.92 kg
Supported Frequency Range:  5.15-5.85 GHz
Gain: 16 dBi
HPOL Beamwidth: 90°
VPOL Beamwidth: 90°
Elevation Beamwidth: 45°
Cross-Pol isolation: 13 dB
Maximum VSWR: 2:1
Wind Survivability: 200 km/h
Wind Loading: 46N - 200 km/h
Polarization: Dual-Linear


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 24 month(s)
