Ubiquiti EP-54V-150W-DC, EdgePower 54v 150W - DC
[2014][EP-54V-150W-DC]

Price: 68,34€

Prices exclude VAT

In Stock: 2

Available quantity within
3-5 working days: 43

Order Qty:

UPC:	810354025730

EP-54V-150W-DC

Optional power supply module for EdgePower 54V 150W, which has a secondary PSU module bay.

The module is hot-swappable and may works as backup PSU or for increasing the DC output power to 300W.

In backup mode, the secondary PSU remains inactive and offline.

If failure of the primary PSU is detected, the secondary PSU automatically activates to supply continuous power.

Product Links:
Datasheet	Quick Start Guide

Specifications:
Power Method:	DC/DC 150W for 22 - 60V Input, DC Terminal Block for 54V Output
Power Supply:	DC/DC 150W for 22 - 60V Input
Supported Voltage Range:	DC/DC for 22 - 60V Input, 54V Output
Battery Type:	2/3/4 Series Lead Acid Battery
Maximum Charging Voltage: 2 Series 3 Series 4 Series	26.8 - 27.5V 40.2 - 41.2V 53.6 - 55V
Discharge Protection Voltage: 2 Series 3 Series 4 Series	21.5V 32V 43V
Charging Current: 2 Series 3 Series 4 Series	0.3A 0.3A 0.2A
LED:	System On/Off
Operating Temperature:	0 to 40°C
Operating Humidity:	10 to 90% RH
ESD/EMP Protection:	Air ± 8KV; Contact ± 6KV
Certifications:	CE, FCC, IC

Package Contents:
1 x EdgePower EP-54V-150W-DC

Additional Images:

Return for:
Refund:	Store Credit:	Repair:
20 day(s)	40 day(s)	24 month(s)
