EZ-RJ456UTL - Cat.6, RJ45 Unshielded Connector, Tool Free - 1 pc
[3151][EZ-RJ456UTL]

Price: 2,00€

Prices exclude VAT

In Stock: 18

Order Qty:

UPC:	728615666922

EZ-RJ456UTL - Cat.6, RJ45 Connector, Tool Free

Easy Assembly - terminate in field in minutes without special tools

Load Bar for Faster and Easier Wire Pattern Termination

Specifications :
Wire Diameter	0.46 to 0.76 mm
Transmission	Cat.6 ISO/IEC11801, TIA568.2-D, EC verified
Complies with	DIN EN 50173-1:2011-09 10 Gbit
Wiring code	T568A or T568B
Color	White
Shielded	No
Power Over Ethernet	PoE, PoE plus, and UPoE
Cable Jacket Diameter	6 to 9.5 mm
Adjustable Strain Relief	6mm to 9.5mm Cable outside diameter
Operating temperature	-40 ~ +60°C
Relative humidity	85% (+30°C), Air pressure: 70-106Kpa
Contact Blades	Phosphor bronze alloy, 50µ gold plated
Intermediate resistance	No more than 20 megohm
Insulated resistance	No less than 1,000 megohm
Retention strength	7.7kg between jack and plug

Package Contents:
1 x EZ-RJ456UTL
