MikroTik Routerboard 153 (Level 4) WISP AP
[0270][RB/153]

The product is
no longer available

Prices exclude VAT

USED!!!

RB/153 adds more interfaces (five LAN and three miniPCI), on same time keeping price low. For those who are concerned how 175Mhz CPU will affect speed- our boards are specially designed for RouterOS to use resources efficiently. Bundled with MikroTik RouterOS this will be your perfect solution

User's Manual

See below table for details:

RouterBOARD 153 Specifications
CPU	MIPS32 4Kc based 175MHz embedded processor
Memory	32MB SDRAM onboard memory chip
Boot loader	RouterBOOT, 1Mbit Flash chip
Data storage	64MB onboard NAND memory chip
Ethernet ports	Five 10/100 Mbit/s Fast Ethernet port supporting Auto-MDI/X
MiniPCI slot	Three MiniPCI Type IIIA/IIIB slots
Speaker	Mini PC-Speaker
Serial ports	One DB9 RS232C asynchronous serial port
LEDs	Power, 2 LED pairs for MiniPCI slots, 1 user LED
Speaker	Mini Speaker present. Can be used for wireless alignment
Power options	IEEE802.3af Power over Ethernet: 12V or 48V DC (except power over datalines) Power jack: 11..60V DC
Power Out	Two 3V DC fan power output headers (only one populated by default), maximal output current - 0.5A total
Power Consumption	3-4W without extension cards. Maximum – 10W
Dimensions	16.0 cm x 16.0 cm (6.3 in x 6.3 in)
Weight	92 g (3.2 oz)
Temperature	Operational: -20°C to +70°C (-4°F to 158°F)
Humidity	Operational: 70% relative humidity (non-condensing)
Currently supported OS	RouterOS 2.9.12

The RB153 can be house in this Enclosure :	The RB153 can be powered by this Power Supply :	The RB153 can be powered by this PoE Bundle:

Mikrotik RB153 Black Indoor Case	18v 0.8A Power Supply Desktop	Passive PoE Injector and 18v 0.8A Desktop Power Supply BUNDLE

Attention : The RB153 does NOT fit inside the DCE 7x6x2 Die Cast Enclosure
