Aerial.net :: Ubiquiti ERPOE-5, EdgeRouter POE

PoE » PoE Router » ERPOE-5

Ubiquiti ERPOE-5, EdgeRouter POE
[1455][ERPOE-5]

The product is
no longer available

Prices exclude VAT

UPC:	810354022227

EdgeRouter PoE 5

The EdgeRouter PoE combines 1 million packets per second routing performance with passive PoE support for network devices.

Use it's advanced feature set to run applications on the customizable open platform.

It also supports 24V or 48V passive PoE to power multiple devices on the network.

The EdgeRouter PoE is supported and managed by UNMS (Ubiquiti Network Management System), a comprehensive controller with an intuitive UI.

Product Links:
Datasheet	Quick Start Guide	EdgeOS

Specifications:
Dimensions:	200 x 90 x 30 mm
Weight:	360 g
Power:	24VDC, 2.5A Power Adapter (Included)
Power Input:	24VDC Input (Supported Range: 18 to 26VDC) or 48VDC Input (Supported Range: 38 to 54VDC)
Button:	Reset
Processor:	Dual-Core 500 MHz, MIPS64 with Hardware Acceleration for Packet Processing
System Memory:	512MB DDR2 RAM
On-Board Flash Storage:	2 GB
Certifications:	CE, FCC, IC
Wall-Mount:	Yes
Operating Temperature:	-10°C to 45°C
Operating Humidity:	90% Non-Condensing
Layer 3 Forwarding Performance:
Packet Size: 64 Bytes:	1,000,000 pps
Packet Size: 512 Bytes or Larger:	3 Gbps (Line Rate)
LEDs Per Port:
Serial Console Port:	Power
Data Ports PoE:	Speed/Link/Activity
PoE Configurable Per Port:
Serial Console Port:	N/A
Data Ports:	Off/24V/48V*
Networking Interfaces:
Serial Console Port:	(1) RJ45 Serial Port
Data Ports:	(2) 10/100/1000 Ethernet Router Ports (3) 10/100/1000 Ethernet Router/Switch Ports
Interface/Encapsulation:	Ethernet 802.1q VLAN PPPoE GRE IP in IP Bridging Bonding (802.3ad)
Addressing:	Static IPv4/IPv6 Addressing DHCP/DHCPv6
Routing:	Static Routes OSPF/OSPFv3 RIP/RIPng BGP (with IPv6 Support) IGMP Proxy
Security:	ACL-Based Firewall Zone-Based Firewall NAT
VPN:	IPSec Site-to-Site and Remote Access OpenVPN Site-to-Site and Remote Access PPTP Remote Access L2TP Remote Access PPTP Client
Services:	DHCP/DHCPv6 Server DHCP/DHCPv6 Relay Dynamic DNS DNS Forwarding VRRP RADIUS Client Web Caching PPPoE Server
QoS:	FIFO Stochastic Fairness Queueing Random Early Detection Token Bucket Filter Deficit Round Robin Hierarchical Token Bucket Ingress Policing
Management:	Web UI CLI (Console, SSH, Telnet) SNMP NetFlow LLDP NTP UBNT Discovery Protocol Logging
